Table 44: FB-specific status codes (no error):
DiagCode State Name State Description and Output Setting
0000 Idle The function block is not active (initial state).
Ready = FALSE
Error = FALSE
S_AnyModeSel = FALSE
All S_ModeXSel = FALSE
8005 ModeChanged State after activation or when S_ModeX has changed (unless locked) or
after Reset of an error state.
Ready = TRUE
Error = FALSE
S_AnyModeSel = FALSE
All S_ModeXSel = FALSE
8000 ModeSelected Valid mode selection, but not yet locked.
Ready = TRUE
Error = FALSE
S_AnyModeSel = TRUE
S_ModeXSel = Selected X is TRUE, others are FALSE.
8004 ModeLocked Valid mode selection is locked.
Ready = TRUE
Error = FALSE
S_AnyModeSel = TRUE
S_ModeXSel = Selected X is TRUE, others are FALSE.
4.6.6.5 SF_EmergencyStop
Standards Requirements
EN 418: 1992 3. Definitions
4.1.12 … Resetting the control device shall not by itself cause a restart command.
EN 954-1: 1996 5.4 Manual reset
ISO 12100-2:
2003
4.11.4 Restart following power failure/spontaneous restart
EN 16204-1, 1997 9.2.2. Stop Functions
Configuration and programming
AC500-S Libraries > SafetyBlocks_PLCopen_AC500_v22.lib
