Function Block-Specific Error and Status Codes
Table 52: FB-specific error codes
DiagCode State Name State Description and Output Setting
C001 Reset Error Static reset detected in state 8003.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = TRUE
C011 Discrepancy-
time Error 1
DiscrepancyTime elapsed in state 8004.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = TRUE
C012 Discrepancy-
time Error 2
DiscrepancyTime elapsed in state 8014.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = TRUE
Table 53: FB-specific status codes (no error):
DiagCode State Name State Description and Output Setting
0000 Idle The function block is not active (initial state).
Ready = FALSE
S_GuardMonitoring = FALSE
Error = FALSE
8000 Normal Safety guard closed and Safe state acknowledged.
Ready = TRUE
S_GuardMonitoring = TRUE
Error = FALSE
8001 Init Function block has been activated.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = FALSE
8002 Open Guard
Request
Complete switching sequence required.
Ready = TRUE
S_GuardMonitoring = FALSE
Error = FALSE
