Table 69: FB Name: SF_MutingPar
Name Data Type Initial Value Description, Parameter Values
VAR_INPUT
Activate BOOL FALSE
Ä Table 31 “General Input Parameters”
on page 266
S_AOPD_In BOOL FALSE Variable.
OSSD signal from AOPD.
FALSE: Protection field interrupted.
TRUE: Protection field not interrupted.
MutingSwitch11 BOOL FALSE Variable.
Status of Muting sensor 11.
FALSE: Muting sensor 11 not actuated.
TRUE: Workpiece actuates muting sensor 11.
MutingSwitch12 BOOL FALSE Variable.
Status of Muting sensor 12.
FALSE: Muting sensor 12 not actuated.
TRUE: Workpiece actuates muting sensor 12.
MutingSwitch21 BOOL FALSE Variable.
Status of Muting sensor 21.
FALSE: Muting sensor 21 not actuated.
TRUE: Workpiece actuates muting sensor 21.
MutingSwitch22 BOOL FALSE Variable.
Status of Muting sensor 22.
FALSE: Muting sensor 22 not actuated.
TRUE: Workpiece actuates muting sensor 22.
S_MutingLamp BOOL FALSE Variable or constant.
Indicates operation of the muting lamp.
FALSE: Muting lamp failure.
TRUE: Muting lamp no failure.
MutingEnable BOOL FALSE Variable or constant.
Command by the control system that enables the
start of the muting function when needed by the
machine cycle. After the start of the muting func-
tion, this signal can be switched off.
FALSE: Muting not enabled
TRUE: Start of Muting function enabled
S_StartReset BOOL FALSE
Ä Table 31 “General Input Parameters”
on page 266
Configuration and programming
AC500-S Libraries > SafetyBlocks_PLCopen_AC500_v22.lib
