DiagCode State Name State Description and Output Setting
CYx4 Error Muting
sequence
Error detected in muting sequence state 8000, 8011, 8311, 8012, 8021,
8014, 8314, 8122, 8422, 8121, 8112, 8114 or 8414.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
Y = Status in the sequence (6 states for forward and 6 states for backward
direction).
C0x4 = Error occurred in state 8000
C1x4 = Error occurred in state Forward 8011
C2x4 = Error occurred in state Forward 8311
C3x4 = Error occurred in state Forward 8012
C4x4 = Error occurred in state Forward 8014
C5x4 = Error occurred in state Forward 8314
C6x4 = Error occurred in state Forward 8021
C7x4 = Error occurred in state Backward 8122
C8x4 = Error occurred in state Backward 8422
C9x4 = Error occurred in state Backward 8121
CAx4 = Error occurred in state Backward 8114
CBx4 = Error occurred in state Backward 8414
CCx4 = Error occurred in state Backward 8112
...
CFx4 = Muting Enable missing
x = Status of the sensors when error occurred (4 bits: LSB = MS_11;
MS_12; MS_21; MSB = MS_22).
C005 Parameter
Error
DiscTime11_12, DiscTime21_22 or MaxMutingTime value out of range.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
C006 Error Timer
MaxMuting
Timing error: Active muting time (when S_MutingActive = TRUE) exceeds
MaxMutingTime.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
Configuration and programming
