Function Block-Specific Error and Status Codes
Table 70: FB-specific error codes
DiagCode State Name State Description and Output Setting
C001 Reset Error 1 Static Reset condition detected after FB activation in state 8001.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
C002 Reset Error 2 Static Reset condition detected in state 8003.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
C003 Error Muting
Lamp
Error detected in muting lamp.
Ready = TRUE
S_AOPD_Out = FALSE
S_MutingActive = FALSE
Error = TRUE
