Error
class
Compo-
nent or
Inter-
face
Device Module Channel Error Error text Remedy
E3 1 or 9 255 30 1 27 Error in config-
uration data,
Safety PLC
cannot read
configuration
data
Create boot project
E4 1 or 9 255 30 2 13 Flash write
error (produc-
tion data)
Warning
E4 1 or 9 255 30 4 13 Flash write
error (boot
project)
Warning
E4 1 or 9 255 30 5 13 Flash write
error (boot
code)
Warning
E4 1 or 9 255 30 6 13 Flash write
error (firm-
ware)
Warning
E4 1 or 9 255 30 7 13 Flash write
error (pass-
word)
Warning
E4 1 or 9 255 30 8 13 Flash write
error (user
data)
Warning
E4 1 or 9 255 30 9 13 Flash write
error (user
data)
Warning
E4 1 or 9 255 30 10 13 Flash write
error (internal)
Warning
E4 1 or 9 255 30 11 13 Flash write
error (internal)
Warning
E4 1 or 9 255 30 12 13 Flash write
error (internal)
Warning
E4 1 or 9 255 30 1 4 Boot project
not loaded,
maximum
power dip
reached
Restart Safety PLC
E4 1 or 9 255 30 1 19 CRC error
boot project
Create new boot project
and restart Safety PLC
E4 1 or 9 255 30 1 0 Reserved
switch address
setting.
Warning
AC500-S Safety Modules
SM560-S Safety CPU > Diagnosis and LED status display
