54 Installing the drive
ACH550-01 User's Manual
11. Connect the control cables. See Control wiring (IP54) on
page 55.
12. Replace the front cover. See Re-install cover (IP54) on
page 63.
Tightening torques
Frame
size
Tightening torque
U1, V1, W1
U2, V2, W2
Earthing PE
N·m (lbf·ft) N·m (lbf·ft) N·m lbf·ft
R1 0.8 (0.6) 1.4 (1.0) 1.4 1
R2 0.8 (0.6) 1.4 (1.0) 1.4 1
R3 2 (1.5) 1.8 (1.3) 1.8 1.3
Auxiliary contact: 0.8 N·m (0.6 lbf·ft)
