ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
3BSE 015 953R201 Rev B 8-25
Table 8-44. Redundant Analog Input Sets for S100 I/O
Description Consists of Article No.
With redundancy: 32 channels, resolu-
tion 12 bits, single- ended 0 to +10 V or
0 to +20 mA, shunt 250 Ω 0.05%
2 x DSAI 133
2 x DSTA 002A
2 x DSTK 222L3
or
2 x DSAI 133A
2 x DSTA 002B
2 x DSTK 222L3
3BSE019915R1
Table 8-45. Analog Output Sets for S100 I/O
Description Consists of Article No.
4 channels, resolution 12 bits, 0 to ±10 V or
0 to ±20 mA, galvanic isolation
DSAO 110
DSTA 160
DSTK 223L3
3BSE019916R1
8 channels, resolution 12 bits, 0 to ±10 V or
0 to ±20 mA
DSAO 120
DSTA 170
DSTK 223L3
3BSE019917R1
16 channels, resolution 8 bits, 0 to +10 V or
0 to +20 mA
DSAO 130
DSTA 180
DSTK 221L3
3BSE019918R1
8 channels, resolution 12 bits, 0 to ±10 V or
0 to ±20 mA, galvanic isolation
DSAO 120A
DSTA 171
DSTK 221L3
3BSE020419R1
16 channels, resolution 12 bits, 0 to +20 mA DSAO 130A
DSTA 181
DSTK 221L3
3BSE020420R1
Table 8-46. Analog Input/Output Sets for S100 I/O
Description Consists of Article No.
8 input channels, resolution 12 bits,
single-ended, 0 to +10 V or 0 to +20 mA,
shunt 250 Ω 0.05%
8 output channels, resolution 12 bits,
0 to +20 mA or 0 to +10 V
(over shunt 500 Ω 0.1% on DSTA 001A or
DSTA 001B)
DSAX 110
DSTA 001A
DSTK 223L3
or
DSAX 110A
DSTA 001B
DSTK 223L3
3BSE019919R1

ABB Advant Controller 450 Specifications

General

Brand	ABB
Model	Advant Controller 450
Category	Controller
Language	English
