Advant Controller 450 Product Guide
3BSE 015 953R201 Rev B 8-28
Terminal unit for distribution of 24V d.c. to
DSTD 108, DSTD 195/197/198
DSSX 166 5347049-CR
Voting unit to DSTD 108, DSTD 195/196/198 if
redundant 24V is used
SS110 3BSE007698R1
Table 8-50. Digital Output Sets for S100 I/O
Description Consists of Article No.
32 channels, 24-250 V a.c./d.c.
Connection unit with 8 relay channels
Input: 24 V d.c. Output: 24-250 V a.c./d.c.
(1)
Connection unit with 8 relay channels
Input: 24 V d.c. Output: 24-250 V a.c./d.c.
(2)
Connection Unit with 8 static
Outputs, 24 V d.c. 2 A.
DSDO 115
DSTK 226L3
or.
DSDO 115A
DSTK 226L3
DSTD 108
or
DSTD 108P
DSTD 108L
or
DSTD 108LP
DSTD 109P
3BSE019931R1
5716 0001-ABD
3BSE018333R1
5716 0001-ABW
3BSE018335R1
3BSE018327R1
32 channels, 24 V d.c., short-circuit proof tran-
sistor outputs, max 150 mA
32 channels, 24 V d.c., short-circuit proof tran-
sistor outputs, max 500 mA
DSDO 115
DSTD 190
DSTK 221L3
or
DSDO 115A
DSTD 190V1
DSTK 234L3
3BSE019932R1
32 channels, 24 V d.c., short-circuit proof tran-
sistor outputs with disconnectible screw terminal
blocks, max 150 mA
DSDO 115
DSTD 110A
DSTK 221L3
or
DSDO 115A
DSTD 110A
DSTK 221L3
3BSE019933R1
16 channels, 24/48 V d.c., transistors outputs,
max. 1 A
DSDO 120
DSTD 120A
DSTK 220L3,2
3BSE019934R1
(1) Relay data: Load current: max. 3 A, min. 0.1 A at 24 V or 2.5 VA.
Breaking capacity a.c. max 720 VA at cos F > 0.4 d.c. max. 44 W at L/R <40 ms
(2) Relay data: Load current: max. 200 mA, min. 1 mA or 0.05 VA.
Breaking capacity a.c. 5 VA at cos F > 0.4, d.c. 5 W at L/R <40 ms
Table 8-49. Digital Input Sets for S100 I/O (Continued)
Description Consists of Article No.
