ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
3BSE 015 953R201 Rev B 8-29
Table 8-51. Connection of Thyristor Converters
Description Consists of Article No.
Set for connection of one controlled
thyristor converter to AC 400 Series
DSDC 111
DSTX 110
DSTK 224L3
3BSE019935R1
Table 8-52. S100 I/O boards for HART Protocol Interface
Description Consists of Article No.
32 channels, resolution 12 bit, single-ended 0
to +10 V or 0 to +20 mA,
shunt 250 Ω 0.05%
DSAI 133
2xDSTA 002A
DSTK 231L5
or
DSAI 133A
2xDSTA 002B
DSTK 231L5
3BSE019936R1
With redundancy: 32 channels, resolution 12
bits, single- ended 0 to +10 V or
0 to +20 mA, shunt 250 Ω 0.05%
2xDSAI 133
2xDSTA 002A
DSTK 222L3
DSTK 231L5
or
2xDSAI 133A
2xDSTA 002B
DSTK 222L3
DSTK 231L5
3BSE019937R1
16 channels, resolution 12 bits,
0 to ±10 V or 0 to ±20 mA
2xDSAO 120
2xDSTA 170
DSTK 232L5
3BSE019938R1
16 channels, resolution 12 bits, 0 to +20 mA DSAO 130A
DSTA 181
DSTK 240L5
3BSE020425R1
8 channels, resolution 12 bits,
0 to ±10 V or 0 to ±20 mA
DSAO 120
DSTA 170
DSTK 232L5
3BSE019939R1
