Section 6.5.3 Communication Buses
3BSE 015 953R201 Rev B 6-7
LONWORKS Network CI572 2 SC510, SC520 4
(6)
GCOM CI543 1 SC510, SC520 5
(7)
RCOM/RCOM+ communication
Multivendor Interface:
- MODBUS
- Siemens 3964(R)
- Allen-Bradley DF1
- Free-programmable MVI
CI532V01
CI532V02 or
CI534V02
CI532V03
CI534V04
CI535 or
CI538
2 SC510, SC520 5
(7)(8) ,
Telecontrol & SPA Bus CI535V23
CI535V24
CI535V26
CI535V29
CI535V30
1 SC510, SC520 5
(7)
MasterFieldbus CI570 1 SC510, SC520 7
Advant Fieldbus 100 CI522A 1 SC510, SC520 14
(9)
Program Card Interface MB510 - SC510, SC520 4
Free-programmable module PU535 - SC510, SC520 12
(1) The total number of submodules may not exceed 14.
(2) 1 port for printer, 2 ports for EXCOM and 4 ports for MasterView 320.
(3) Only one CS513 on each SC520 when MasterBus 300/MasterBus 300E is executed in main CPU.
(4) MasterBus 300/300E in main CPU and in slave CPU can not be mixed within the same controller.
(5) The total number of MasterBus 300 and MasterBus 300E in main CPU is 2
(6) The maximum number of PROFIBUS-DP plus L
ONWORKS Network plus single/redundant Advant Fieldbus 100 is 8.
(7) The total number of submodules for MVI, RCOM, GCOM and Telecontrol & SPA Bus is 5.
(8) Max number of physical channels used are 9 (limited in software).
(9) 8 redundant Advant Fieldbus 100 give a maximum of 16 submodules but the available number of slots for submodules (on
carrier modules) limits the maximum to 14.
Table 6-6. Submodules mounted in submodule carriers (Continued)
