AQUAMASTER4 | ELECTROMAGNETIC FLOWMETER TRANSMITTER | OI/FET400-EN REV. D 53
Logger Settings*
#
Description Note
Flow and pressure logging interval
(seconds)
Used to enter an interval time in seconds between logging of flow and pressure values.
Readable level 3
Writable level 4
Flow and pressure retrieved record
interval (seconds)
Used to enter an interval time in seconds between data capture when retrieving flow and pressure
values
Editable
Totalizer Logging Hour Hour of day totals are recorded Editable
Clear Logging Data Erases all logging data Editable
Earliest Logger Data/Time Informs start date/time of log
Pulse Output Settings Description Note
Pulse Outputs Configuration Used to enable/disable pulse outputs. Options: Disabled/Enabled
Editable,
default: Disabled
Pulses Per Unit Volume
Used to enter a value (the quantity) of pulses per unit volume. Ensure Enabled is selected at the
Pulse Outputs Configuration parameter before entering a value at this parameter.
Editable
Pulse Width (ms) Used to enter the pulse duration (in ms) Editable
Max Available Pulse Frequency (Hz) Maximum frequency for a given pulse width Read-only
* Use of high pulse output frequencies and long pulse widths will significantly shorten battery life. Ideally F≤ 5 Hz with width ≤ 2 ms.
Alarm Output Settings Description Note
Clear All Alarms Erases all alarm state Editable
Alarm Output Configuration Used to enable / disable alarm output. Options: Disabled | Always on | Normally off | Normally on
Editable,
default: Disabled
Totalizer Rollover 0 (Off), 1 (On) Read-only
Totalizer Reset 0 (Off), 1 (On) Read-only
Flow Sensor Communications 0 (Off), 1 (On) Read-only
High Flow Alarm 0 (Off), 1 (On) Read-only
Low Flow Alarm 0 (Off), 1 (On) Read-only
Empty Pipe 0 (Off), 1 (On) Read-only
Pulse output saturated 0 (Off), 1 (On) Read-only
Battery Power Low Warning 0 (Off), 1 (On) Read-only
Power Management Settings Description Note
System power type Battery | Mains | Renewable (Factory-set) Read-only
Current power source Mains, AC power, Internal battery supply Read-only
Measurement interval (seconds) 15 s – factory setting Read-only
Internal supply voltage (V) Current on-board power supply voltage in voltage Read-only
Simulation modes
*
Description Note
Flow Simulation Mode Used to select the simulation mode. Options: Off | Velocity (mm/s) | Flow (system units) Editable
Flow Simulation Value Used to set a value for flow simulation. Editable
Pulse Output Simulation
Configuration
Used to select the simulation mode for pulse outputs. Options: Off | Forward (DO1) | Reverse (DO2) Editable
Pulse Output Simulation Frequency Range 0 to 50 Hz Editable
Pressure Simulation Mode Options: Off/On Editable
Pressure Simulation Value Used to set a value for pressure simulation Editable
#
Logger Settings availble with FEX41X/43X only.
* Totalizer changes while a simulation mode is enabled are not saved in non-volatile memory and are reversed when the simulation mode is disabled.
