54 AQUAMASTER4 | ELECTROMAGNETIC FLOWMETER TRANSMITTER | OI/FET400-EN REV. D
…7 Operation
...Configuration
User Access Rights Settings Description Note
Current Access Level The current level of access Default at Level 3
Transmitter Unique ID Read-only
Elevated Access PIN Read-only
Change User Access Password Used to enter a different/new access password Editable
Confirm User Access Password
Change
Used to re-enter/confirm the access password set at the Change User Access Password menu Editable
Elevated Access Request
Transmitter unique ID (see above) and Elevated Access PIN. Enter into 'Hasher',' result of 'Hasher' is a
string; enter the value in this field.
Editable
Advanced Access Level Enable Enables/Disable advanced level access Editable
User Password Reset PIN Read-only
User Password Reset Request
Transmitter unique ID (see above) and User Password Reset PIN. Enter into 'Hasher',' result of 'Hasher'
is a string; enter the value in this field.
Editable
Lock Switch Function Indicator MID settings Editable
Sensus Settings *
Note
Sensus Serial Number
Editable
Sensus Totalizer Source:
Editable
0 Totalizer Fwd x 1
1 Totalizer Rev x 1
2 Totalizer Net x 1
3 Totalizer Fwd x 10
4 Totalizer Rev x 10
5 Totalizer Net x 10
6 Totalizer Fwd x 100
7 Totalizer Rev x 100
8 Totalizer Net x 100
* Applicable only to flowmeters ordered with Sensus AMR enabled.
Modbus Settings
Note
Modbus Device Address Editable
Modbus Port Settings
Editable
18 9600Bd 7-bit no parity
19 9600Bd 7-bit odd parity
20 9600Bd 7-bit even parity
21 9600Bd 8-bit no parity
22 9600Bd 8-bit odd parity
23 9600Bd 8-bit even parity
24 19200Bd 7-bit no parity
25 19200Bd 7-bit odd parity
26 19200Bd 7-bit even parity
27 19200Bd 8-bit no parity
28 19200Bd 8-bit odd parity
29 19200Bd 8-bit even parity
Modbus Most Significant Register First Format
Editable
0 off
1 on
* Applicable only to flowmeters ordered with Modbus enabled.
