29
100.0
rEt HI
100.0
rEt LO
CNt HI
•1
•1
4 CONFIGURATION MODE…
…4.4 Ranges and Passwords (Level 4)
Retransmission Range
The retransmission range defines the the engineering
range to be retransmitted.
High (20mA output)
[–9999 to 99999 (in engineering units)]
Low (4mA output)
[–9999 to 99999 (in engineering units)]
Continued on next page…
•1 The retransmission range high and low values are automatically set to the
maximum allowed value when thermocouple or RTD is selected in the
configuration level – see Section 4.3.1. This value can be modified if required.
