30
100.0
CNt HI
1.00
cut.oFF
0
PASSrd
1
Addr.
•1
•1
•2
…4 CONFIGURATION MODE
…4.4 Ranges and Passwords (Level 4)
Totalizer Count High
This frame determines the count corresponding to the
full-scale input.
[0.000 and 99.999 pulses/second]
Cut-off
This frame sets the lowest flow value at which the
totalizer is to stop counting.
[In engineering units]
Setup Password
This password enables access to the setup level (levels
2).
[0 to 9999]
Modbus Address
This frame sets the Modbus address.
[1 to 99]
•1 Only displayed if enabled in the configuration level – see Section 4.3.3.
•2 Only available if the appropriate option board is fitted.
