Introducing the CoreSense M10 13
—
Figure 3 Overview of the CoreSense M10 analytical unit (open)
Touchscreen
Cable cover
Communication
ports
Analytical unit
bulkhead fitting
External
communication
entry port
Power entry port
Status lights
(from back)
Relay module
and power entry
terminal block
