ABB CoreSense M10 - Hydrogen Sensor Data Diagnostics

92 Installation Guide
Connector Connection Type Wire Screwdriver
E
HU AC live
120–240 V AC
50/60 Hz
3.15 A max.
Copper only wire
Stranded AWG #18
WITH FERRULE
Flat screwdriver Ø 3.5 mm
F
HU AC neutral
G
HU AC earth
H
AC earth
120–240 V AC
50/60 Hz
8 A max.
Copper only wire
Stranded AWG #18
to AWG #12 WITH
FERRULE
OR
Solid AWG #18 to
AWG #12
Flat screwdriver Ø 3.5 mm
I
AC live
Flat screwdriver Ø 6 mm
or Phillips #2
J
AC neutral
NOTICE
All terminals are properly identified in the instrument itself to simplify installation.
