44 EL3000 CONTINUOUS GAS ANALYZERS | CI/EL3000-EN REV. C

… 4 Installation

… Position and design of the gas connections

Uras26: Gas connections for pipelines

(internal gas lines made stainless steel pipes)

Pos.

Connection

Supplementary information

Version

Pressure sensor

—

Screwed connections with hose nozzles (stainless

steel

1.4305) for hoses with 4 mm inside diameter

(included in scope of supply)

Sample gas inlet

—

⅛ NPT female thread (stainless steel 1.4305) for

threaded connections

(not included in scope of supply)

Sample gas outlet

For a sample cell

Sample gas outlet

For two sample cells in series

Note

The oxygen sensor, the ‘integrated gas feed’ option and the version with separated gas paths are not possible.
