ABB EC Titanium Series User Manual

10-10 Parameter Denitions MN448
Parameters in the Long parameter mode
No. Name/Value Description Default
15 ANALOG/DIGITAL OUTPUTS Analog output signal processing
1501
ANALOG OUTPUT
FUNCTION SELECT
Selects the type of output signal information indicated from terminal 8.
Note: When using settings 0 - 7 the output is a digital format (Logic 1 =
24V). When using settings 8-10 the output is an analog format.
8
0: DRIVE ENABLED
(RUNNING)
Logic 1 when the DRIVE is enabled (Running)
1: DRIVE READY Logic 1 When no Fault condition exists on the drive
2: AT TARGET
FREQUENCY (SPEED)
Logic 1 when the output frequency matches the set-point frequency
3: DRIVE TRIPPED Logic 1 when the drive is in a fault condition
4: OUTPUT FREQUENCY
>= LIMIT
Logic 1 when the output frequency exceeds the adjustable limit set in
parameter 3200 RELAY THRESHOLD LEVEL
5: OUTPUT CURRENT >=
LIMIT
Logic 1 when the motor current exceeds the adjustable limit set in
parameter
3200 RELAY THRESHOLD LEVEL
6: OUTPUT FREQUENCY
< LIMIT
Logic 1 when the output frequency is below the adjustable limit set in
parameter 3200 RELAY THRESHOLD LEVEL
7: OUTPUT CURRENT <
LIMIT
Logic 1 when the motor current is below the adjustable limit set in
parameter
3200 RELAY THRESHOLD LEVEL
8: OUTPUT FREQUENCY
(MOTOR SPEED)
0 to parameter 2008 MAXIMUM FREQUENCY / SPEED LIMIT
9: OUTPUT (MOTOR)
CURRENT
0 to 200% of parameter 9906 MOTOR RATED CURRENT
10: MOTOR POWER 0 to 200% of drive rated power.
16 SYSTEM CONTROLS Parameter lock etc.
1602
PARAMETER ACCESS
UNLOCK
If Parameter 1603 has had a value entered, then the matching value needs
to be entered here in order to give read-write access to the parameters.
Refer to section 10.4 for detailed operation.
0
0…65535
1603
PARAMETER ACCESS CODE
DEFINITION
To make all parameters Read only, enter a value in this parameter. Refer to
section 10.4 for detailed operation.
0
0…65535
20 LIMITS
Drive operation limits
2007
MINIMUM FREQUENCY /
SPEED LIMIT
Minimum output frequency or motor speed limit – Hz or rpm.
If 9908 MOTOR RATED SPEED >0, the value entered / displayed is in RPM
0.0 Hz
0.0 HZ…2008
Minimum frequency
2008
MAXIMUM FREQUENCY /
SPEED LIMIT
Maximum output frequency or motor speed limit – Hz or rpm.
If 9908 MOTOR RATED SPEED >0, the value entered / displayed is in RPM
133.0 Hz
2007…500.0 Hz
Maximum frequency
2020 BRAKE CHOPPER ENABLE
0
0: MOTOR POWER
1:
ENABLED WITH
SOFTWARE
PROTECTION
Enables the internal brake chopper with software protection for a 200W
continuous rated resistor
2:
ENABLED WITHOUT
SOFTWARE
PROTECTION
Enables the internal brake chopper without software protection. An external
thermal protection device should be tted.
3:
ENABLED WITH
SOFTWARE
PROTECTION
As setting 1, however the Brake chopper is only enabled during a change
of the frequency set-point and is disabled during constant speed operation.
4:
ENABLED WITHOUT
SOFTWARE
PROTECTION
As setting 2, however the Brake chopper is only enabled during a change
of the frequency set-point and is disabled during constant speed operation.
