ABB EC Titanium Series User Manual

Parameter Denitions 10-11MN448
Parameters in the Long parameter mode
No. Name/Value Description Default
21 START/STOP Start and Stop modes of the motor
2101 FLYING START
Starting the drive connected to a rotating motor.
Size 2 drives only, DC injection time on start for Size 1 drives
2
0: DISABLED
1:
ENABLED
When enabled, on start up the drive will attempt to determine if the motor is
already rotating, and will begin to control the motor from its current speed.
A short delay may be observed when starting motors which are not turning/
On Size E1 only this parameter Sets a time for which DC current is injected
into the motor to ensure it is stopped when the drive is enabled.
2:
ENABLED ON TRIP,
BROWN OUT OR
COAST STOP
Spin start is only activated following the events listed, otherwise it is
disabled
2102 STOP MODE Selects the motor stop function
Setting On Disable On Mains loss
0 Ramp to Stop (2203 DECEL
RAMP TIME)
Ride Through (Recover energy
from load to maintain operation)
1 Coast Coast
2 Ramp to Stop (2203 DECEL
RAMP TIME)
Fast Ramp to Stop (2206 2nd
DECEL RAMP TIME), coast if
2206 is zero.
3 Ramp to Stop (2203 DECEL
RAMP TIME) with AC ux
braking
Fast Ramp to Stop (2206 2nd
DECEL RAMP TIME), coast if
2206 is zero.
0
2104
DC INJECTION TIME ON
STOP
Denes the time for which a DC current is injected into the motor once the
output frequency reaches 0.0Hz. The voltage level is the same as the boost
level set in parameter 2603.
Duration
Index 1 0.0
0.0…25.0 s
Denes the time for which DC current is injected into the motor. The voltage
level is the same as the boost level set in parameter 2603.
DC INJECTION MODE
Index 2 0
0
DC injection on STOP at the voltage level set in 2603 after the output
frequency has reached 0.0Hz and for the time set in Index 1. This can be
useful to ensure the motor has reached a complete stop before the drive
disables.
1
DC injection on START at the voltage level set in 2603 and for the time
set in Index 1 immediately after the drive is enabled, prior to the output
frequency ramping up from zero. This can be used to ensure the motor is at
a standstill prior to starting.
2
DC injection on STOP and START (at both of the settings 0 and 1 above).
2108
TERMINAL MODE
RESTART FUNCTION
Denes the behavior of the drive relating to the enable digital input and also
congures the Automatic Restart function.
Auto-0
Edge-r
Following Power on or reset, the drive will not start if Digital Input 1 remains
closed. The Input must be closed after a power on or reset to start the
drive.
Auto-0
Following a Power On or Reset, the drive will automatically start if Digital
Input 1 is closed.
Auto- to Auto-5
Following a trip, the drive will make up to 5 attempts to restart at 20 second
intervals. The drive must be powered down to reset the counter. The
numbers of restart attempts are counted, and if the drive fails to start on
the nal attempt, the drive will fault and will require the user to manually
reset the fault.
