F L O W- X INS T R U C T I O N M A N U A L | I M/ F L O W X - EN 39
Power consumption
Values at 24 Vdc excluding supply of external transmitter loops.
Nominal
Peak at start up
Flow-X/P0
0.3 A
0.8 A
Flow-X/C
0.5 A
1.0 A
Flow-X/M (flow module)
0.3 A
0.8 A
The power supply input circuits of the Flow-X/P0 and the Flow-
X/M flow modules are equipped with an auto-fuse rated at 30
Vdc and 1.1 A each.
E.g. a Flow-X/P4, which is a Flow-X/P with 4 Flow-X/M flow
modules has a nominal power consumption of 1.5 A (0.3A of
Flow-X/P0 + 4 * 0.3 A for each flow module) and a peak
consumption of 4.0 A at startup.
Weight
Individual component
Enclosure
Weight in kg
Weight in lbs
Flow-X/S (without flow module)
1.7
3.7
Flow-X/K (without flow module)
0.9
2.0
Flow-X/R (without flow modules)
5.0
11.0
Flow-X/B
1.2
2.6
Version 1
Enclosure
Weight in kg
Weight in lbs
Flow-X/M (single flow module)
0.8
1.7
Flow-X/P0 (without flow modules)
3.7
8.2
Version 2
Enclosure
Weight in kg
Weight in lbs
Flow-X/M (single flow module)
0.9
1.9
Flow-X/P0 (without flow modules)
4.1
8.9
Flow-X/C
2.7
6.0
Combined product
Version 1
Enclosure
Weight in kg
Weight in lbs
Flow-X/S including flow module
2.5
5.4
Flow-X/K including flow module
1.7
3.6
Flow-X/P1
4.5
9.8
Flow-X/P2
5.2
11.5
Flow-X/P3
6.0
13.1
Flow-X/P4
6.7
14.8
Flow-X/R1
5.8
12.7
Flow-X/R2
6.5
14.3
Flow-X/R3
7.3
16.0
Flow-X/R4
8.0
17.6
Flow-X/R5
8.8
19.3
Flow-X/R6
9.5
20.9
Flow-X/R7
10.3
22.6
Flow-X/R8
11.0
24.3
Version 2
Enclosure
Weight in kg
Weight in lbs
Flow-X/S including flow module
2.6
5.7
Flow-X/K including flow module
1.8
3.9
Flow-X/P1
4.9
10.9
Flow-X/P2
5.5
12.0
Flow-X/P3
6.3
14.0
Flow-X/P4
7.2
15.9
Enclosure
Weight in kg
Weight in lbs
Flow-X/R1
5.9
13.0
Flow-X/R2
6.8
14.9
Flow-X/R3
7.6
16.8
Flow-X/R4
8.5
18.8
Flow-X/R5
9.4
20.7
Flow-X/R6
10.3
22.7
Flow-X/R7
11.2
24.6
Flow-X/R8
12.0
26.5
