F L O W- X INS T R U C T I O N M A N U A L | I M/ F L O W X - EN
9 Technical specifications
General
Version 1 Hardware
Item
Type
Description
Quantity
Temperature
Operating
Operating range temperature
0 .. 60 °C
Temperature
Storage
Storage range temperature
-20 .. 70 °C
Processor
Freescale
i.MX processor with math coprocessor, and FPGA
400 MHz
Memory
RAM
Program memory
128 MB
Storage
SLC
Storage memory for data logging, OS and firmware
1024 MB
Clock
RTC
Real time clock with internal lithium cell
Accuracy better than 1 s/day
Version 2 Hardware
Item
Type
Description
Quantity
Temperature
Operating
Operating range temperature
0 .. 60 °C
Temperature
Storage
Storage range temperature
-20 .. 70 °C
Processor
Freescale
i.MX6 processor with math coprocessor, and FPGA
800 MHz
Memory
RAM
Program memory
512 MB
Storage
SLC
Storage memory for data logging, OS and firmware
1024 MB
Clock
RTC
Real time clock with gold cap
Accuracy better than 1 s/day
Other specifications
Item
Type
MTBF
5 years minimum
EMC
EN 61326-1997 industrial locations
EN 55011
Casing
EN 60950
Table 9-1 General Specifications
Flow-X/M I/O specifications
Signal
V1 Nr
V2 Nr
Type
Description
Analog signals
1
Analog input
6
1
6
1
4-20mA,
0-20mA,
0-5V
or 1-5V
Analog transmitter input
High accuracy (error <0.008% FS, resolution 24 bits)
For (for example) 3xdP, P, T.
Inputs are fully floating (optically isolated).
Temperature input
2
2
PRT
Analog PT100 input. -220 - 220 deg.C. for 100 ohms input.
Resolution 0.02 deg.C
Max. error Between 0-50 degC :0.05 deg.C,
Between -220 - +220 degC: 0.5 deg.C
Hart modems
4
1
4
1
HART
Loop inputs for HART transmitters, on top of the first 4 analog input signals.
Analog output
4
4
4-20mA,
0-20mA,
or 1-5V.
Analog output for PID, pressure control valve. 12 bits ADC, 0.075% fs. Update rate 0.1s.
Digital signals
Dual pulse input
1
2
4
2
High impedance
High speed turbine/PD/USM meter input, pulse count. Trigger level 0.5V. Max. level 30 V.
Frequency range 0-5kHz (dual pulse), or 0-10kHz (single pulse).
Compliant with ISO6551, IP252, and API 5.5. True Level A implementation.
Density
4
2
4
2
High impedance
Periodic time input, 100us - 5000us.
Accuracy 30ns, resolution 2 ns
Digital input
16
2
16
2
High impedance
Digital status input, or prover inputs. 0.5ms detect update rate for 2 inputs, others 250ms
max.
Digital output
16
2
16
2
Open collector
Digital output for relays etc. (0.5A DC). Rating 100mA @24V. Update rate at cycle time.
Prover output
1
2
1
2
Open collector
Two related pulse outputs, for proving applications. One output is the highest value of the
dual pulse inputs, and the other output the difference between the dual input pulses. The
outputs are On-Off-HighZ.
Pulse output
4
2
4
2
Open collector
Max. 100Hz
