1.14 Orientation agreements
D
Y
X
Z
B
A
C
A Front side: face forward to the
EVSE during normal use
B Left side
C Right side
D Rear side
X X-direction (positive is to the right)
Y Y-direction (positive is to the front)
Z Z-direction (positive is upward)
