ABB HVC 200 - Parts included in the delivery; Required parts for installation

AGC code Short description Description
ABB6AGC116223 200-2D UL HVC UL 200-2 M-PD-0
ABB6AGC116225 200-4S UL HVC UL 200-4 M-P-0
ABB6AGC116224 200-2S UL HVC UL 200-2 M-P-0
12.2 Parts included in the delivery
Part Specification
Power cabinet Refer to the type plate. Refer to section 3.1.
Key to the power cabinet door Unique for each power cabinet
Key to the DC door Unique for the DC door
Note:
It is possible that more parts need to be included in the delivery.
Refer to the order.
12.3 Required parts for installation
Part Specification
Fasteners and washers, to connect the
charge post to the foundation
M12, class A2, length 70 mm (2.75 in)
Fasteners and washers, to connect the
power cabinet to the foundation
M16, class A2, length 70 mm (2.75 in)
Fasteners and washers, for the earthing
connections
M1
0, class A2, length 70 mm (2.75 in)
Table 2: Cable lugs
Location Wire Size Maximum width Maximum length
[mm] [in] [mm] [in]
Power
cabinet
PE M12 35 1.4 70 2.7
M10 25 70 50 70
M6 12 0.5 40 1.6
AC input power M12 39 1.5 70 2.7
DC power M12 39 1.5 70 2.7
Technical data
HVC 200/300/360-EN | 002 75
