12.14 AC input specifications
12.14.1 200 kW configuration
Parameter Specification
Input AC power connection 3-phase, 480 V AC: PE, L1, L2, L3
Input voltage range 480 V AC +/- 10%
Frequency 60 Hz +/- 4%
Maximum power dissipation 218 kVA
Power factor at full load ≥ 0.95
Efficiency >94% and 96% in power spectrum be-
tween 20% and 100% of full power
Nominal input current 262 A AC
Short-circuit capacity 25 kA
12.14.2 300 kW configuration
Parameter Specification
Input AC power connection 3-phase, 480 V AC: PE, L1, L2, L3
Input voltage range 480 V AC +/- 10%
Frequency 60 Hz +/- 4%
Maximum power dissipation 326 kVA
Power factor at full load ≥ 0.95
Efficiency >94% and 96% in power spectrum be-
tween 20% and 100% of full power
Nominal input current 392 A AC
Short-circuit capacity 25 kA
12.14.3 360 kW configuration
Parameter Specification
Input AC power connection 3-phase, 480 V AC: PE, L1, L2, L3
Input voltage range 480 V AC +/- 10%
Frequency 60 Hz +/- 4%
Maximum power dissipation 391 kVA
Power factor at full load ≥ 0.95
Efficiency >94% and 96% in power spectrum be-
tween 20% and 100% of full power
Nominal input current 470 A AC
Short-circuit capacity 25 kA
