ABB HVC 200 - Interlock + DC guard cable; Ethernet cables; Optical fiber cables

Parameter Specification
Ambient temperature range -40 °C to +80 °C (-40 °F to +176 °F)
Strip length 11 mm (0.43 in)
12.13.9 Interlock + DC guard cable
Parameter Specification
Type Shielded (tinned copper braid)
Number of (twisted) pairs 2x2
Core identification Acc. to DIN 47100
Cross section 0.75-2.5 mm² (20-14 AWG)
Diameter 5-10 mm (0.19-0.39 in)
Conductor Fine strand copper wire
Insulation PVC that is serviceable for outdoor use, UV-
protected, and oil resistant
Characteristic impedance 120 Ω ± 10%
Test voltage 1.5 kV
Ambient temperature range -40 °C to +80 °C (-40 °F to +176 °F)
Strip length 11 mm (0.43 in)
12.13.10 Ethernet cables
Parameter Specification
Type Cat6 or Cat5e, shielded (tinned copper braid)
Number of (twisted) pairs 4 x 2
Core identification Acc. to DIN 47100
Cross section 0.5-0.75 mm² (21-20 AWG)
Diameter 5-10mm (0.19-0.39 in)
Conductor Fine strand copper wire
Insulation PVC that is serviceable for outdoor use, UV-
protected, and oil resistant
Characteristic impedance 120 Ω ± 10%
Test voltage 1.5 kV
Ambient temperature range -40 °C to +80 °C (-40 °F to +176 °F)
12.13.11 Optical fiber cables
Parameter Specification
Type OM3, prefabricated - OM3, PCF or fiberglass
(multimode, 850 nm)
Number of fibers 4 (2 for spare)
Connector type B-FCO(ST
®
)
Technical data
86 HVC 200/300/360-EN | 002
