12.13.2 AC input cables
Parameter Specification
Cable shielding (optional) If the local rules require shielded cables, the
cable shielding must be connected to the PE
rail at both ends of the cable.
Diameter of the phase conductors Refer to the local rules.
Diameter of the PE conductor The same as the diameter of the phase con-
ductors
Maximum diameter of the cable
conductor
240 mm² (500 MCM AWG)
(Recommended)
Insulation Special PVC that is serviceable for outdoor
use, UV-protected, and oil resistant
Ambient temperature range -40 °C to +80 °C (-40 °F to +176 °F)
Strip length 20 mm (0.75 in)
12.13.3 AC auxiliary power cable (3 phase 480 V AC)
Parameter Specification
Type Unshielded
Number of cores 4
Core identification Acc. to IEC 60446
Cross section 2.5 mm² (14 AWG)
Diameter 5-10 mm (0.2-0.4 in)
Conductor Bare copper, fine wired, bunch stranded acc.
to VDE 0295 CI.5/IEC CI.5
Insulation Special PVC that is serviceable for outdoor
use, UV-protected, and oil resistant
Nominal voltage 0.6 KV / 1 kV
Test voltage 4 kV
Ambient temperature range -40 °C to +80 °C (-40 °F to +176 °F)
Strip length 20 mm (0.78 in)
12.13.4 AC auxiliary power cable (1 phase 120 V)
Parameter Specification
Type Unshielded
Number of cores 3
Core identification Acc. to IEC 60446
Cross section 2.5 mm² (14 AWG)
Diameter 6-12 mm (0.23-0.47 in)
Conductor Bare copper, fine wired, bunch stranded acc.
to VDE 0295 CI.5/IEC CI.5
Insulation Special PVC that is serviceable for outdoor
use, UV-protected, and oil resistant
Nominal voltage 0.45 kV / 0.75 kV
Technical data
HVC 200/300/360-EN | 002 83
