Tightening torque (Nm)
Class 12.9, oil-lubric-
ated
Tightening torque (Nm)
Class 10.9, oil-lubric-
ated
Tightening torque (Nm)
Class 8.8, oil-lubricated
Dimension
1150960680M24
Tightening torque for lubricated screws (Molykote, Gleitmo or equivalent) with allen head screws
The following table specifies the recommended standard tightening torque for
screws lubricated with Molycote 1000, Gleitmo 603 or equivalent with allen head
screws.
Note
A special torque specified in the repair, maintenance or installation procedure
overrides the standard torque.
Tightening torque (Nm)
Class 12.9, lubricated
i
Tightening torque (Nm)
Class 10.9, lubricated
i
Dimension
8M5
14M6
3528M8
7055M10
12096M12
300235M16
550460M20
950790M24
i
Lubricated with Molycote 1000, Gleitmo 603 or equivalent
322 Product manual - IRB 1010
3HAC081964-001 Revision: B
© Copyright 2022 ABB. All rights reserved.
9 Reference information
9.4 Screw joints
Continued
