NoteAction
Shown in Location of oil plugs on
page 126.
Remove the oil plug, filling. (Ventilation hole
plug should also be removed.)
3
Tightening torque: 24 Nm.
Art.no. and total amount are specified
in Required equipment on page 127.
Refill gearbox with lubricating oil.
The amount of oil to be filled depends on the
amount that was previously drained.
4
Shown in Location of oil plugs on
page 126.
Refit oil plug,filling and ventilation hole plug.5
Tightening torque: 24 Nm.
Product manual - IRB 660 129
3HAC025755-001 Revision: W
© Copyright 2006-2020 ABB. All rights reserved.
3 Maintenance
3.4.3 Changing oil, gearbox axes 2 and 3
Continued
