ABB IRB 660 - Replacement of Upper Arm

4.4.3 Replacement of upper arm
Location of upper arm
The upper arm is located as shown below.
xx0600002609
Upper armA
Motor axis 6B
Balancing deviceC
Lower armD
Parallel rodE
LinkageF
