3.3.9 Inspection, dampers
Location of dampers
This figure shows the location of dampers.
xx0500002501
Damper, lower arm, upper (2 pcs)A
Damper, lower arm, lower (1 pc)B
Damper, axis 2 (2 pcs)C
Damper, axis 3 (2 pcs). Not visible in this view.-
