AUTOMATIC CONTROL UNIT, OMD100
AUTOMATIC CONTROL UNIT, OMD100
—
4.2 Mounting
4.2.1 Automatic control unit OMD100, door mounting
The automatic control unit OMD100 can be mounted on the door with the fastener OMZD1,
see Accessories, Section 10. Door drilling according to Figure 4.2.
Figure 4.2 Automatic control unit OMD100, door mounting, door drilling
160
KA00446
91
91
2
OMZD1
×2
1
2a
2b
