AUTOMATIC CONTROL UNIT, OMD100
DIP switch S23-1 to set phase system
S23-1 Position Phase system
OFF three-phase (default)
ON single phase
DIP switch S23-2 is not in use.
KA00487
1
2
ON
1
2
ON
Figure 7.6 DIP switches in OMD100, the positions are factory default settings
7.2.2.1 Parameter settings by DIP switches S23
S23
1
2
ON
KA00356
