Electrical connections
32 - EN FEX300, FEX500 CI/FEX300/FEX500-EN
Important (Note)
• Use wire end sleeves.
- Wire end sleeves 0.75 mm
2
(AWG 19), for shielding (1S, 2S)
- Wire end sleeves 0.5 mm
2
(AWG 20), for all other wires
• The shields may not touch (signal short circuit).
en
Prepare the cable end on the transmitter side as shown in Fig. 29.
5.3.1 Cable with part number D173D027U01
• Twist the wire mesh shield of the cable and connect to the ground terminal.
• Connect the ground wire of the cable to the SE clamp of the terminal strip.
• Connect all other wires as shown in Fig. 29.
5.3.2 Cable with part number D173D031U01
• Connect the cable ground wire together with the foil shield continuity wire from D1, D2 to the
SE clamp of the terminal strip.
• When using the flowmeter sensor in systems with cathodic corrosion protection (CCP),
connect the cable ground wire together with the foil shield continuity wire from D1, D2 to the
SE clamp of the terminal strip.
• Connect all other wires as shown in Fig. 29.

ABB ProcessMaster Specifications

General

Type	Electromagnetic Flowmeter
Liner Material	PTFE, PFA, Polyurethane, Rubber
Electrode Material	Stainless steel, Hastelloy, Tantalum, Titanium, Platinum
Process Connection	Flange, Wafer
Fluid Temperature	-40 to 180 °C (-40 to 356 °F) Depending on liner
Output	4-20 mA, HART, PROFIBUS PA, FOUNDATION Fieldbus
Power Supply	100 to 230 V AC, 24 V AC/DC
Protection Class	IP67
Approvals	ATEX, IECEx, FM, CSA
