6.3 Menu levels
Two levels exist under the process display.
Process display
Information level Configuration level
Diagnostics Easy Setup
Operator Page 1 ... 3
Device Info
Autoscroll
Device Setup
Signals View Display
Input/Output
Process Alarm
Communication
Diagnostics
Totalizer
Fig. 48: Menu levels
Process display
The process display shows the current process values.
Information level
The information level contains the parameters and information that are relevant for the user.
The device configuration cannot be changed on this level.
Configuration level
The configuration level contains all the parameters required for device commissioning and
configuration. The device configuration can be changed on this level.
Notice
For a detailed description of the individual parameters and menus at the configuration level
refer to the “Parameterization” section in the corresponding operating instructions.

ABB ProcessMaster Specifications

General

Type	Electromagnetic Flowmeter
Liner Material	PTFE, PFA, Polyurethane, Rubber
Electrode Material	Stainless steel, Hastelloy, Tantalum, Titanium, Platinum
Process Connection	Flange, Wafer
Fluid Temperature	-40 to 180 °C (-40 to 356 °F) Depending on liner
Output	4-20 mA, HART, PROFIBUS PA, FOUNDATION Fieldbus
Power Supply	100 to 230 V AC, 24 V AC/DC
Protection Class	IP67
Approvals	ATEX, IECEx, FM, CSA
