ABB ProcessMaster User Manual

Mounting
16 - EN FEX300, FEX500 CI/FEX300/FEX500-EN
4.2 Torque information
4.2.1 ProcessMaster in flange design and HygienicMaster in flange or wafer-type design
Meter size DN Nominal
pressure
Max. tightening torque [Nm]
Hard/soft rubber lining PTFE, PFA, ETFE lining mm Inch PN
Steel flange Stainless steel
flange
Steel flange Stainless steel
flange
PN40 - - 12.43 12.43
PN63/100 - - 12.43 12.43
CL150 - - 12.98 12.98
CL300 - - 4.94 17.38
3 ... 10
1)
1/10 ...
3/8“
1)
JIS 10K - - 12.43 12.43
PN40 6.74 4.29 14.68 14.68
PN63/100 13.19 11.2 22.75 22.75
CL150 3.65 3.65 12.98 12.98
CL300 4.94 3.86 4.94 17.38
CL600 9.73 9.73 - -
15 1/2“
JIS 10K 2.84 1.37 14.68 14.68
PN40 9.78 7.27 20.75 20.75
PN63/100 24.57 20.42 42.15 42.15
CL150 5.29 5.29 18.49 18.49
CL300 9.77 9.77 33.28 33.28
CL600 15.99 15.99 - -
20 3/4“
JIS 10K 4.1 1.88 20.75 20.75
PN40 13.32 8.6 13.32 8.6
PN63/100 32.09 31.42 53.85 53.85
CL150 5.04 2.84 23.98 23.98
CL300 17.31 16.42 65.98 38.91
CL600 22.11 22.11 - -
25 1“
JIS 10K 8.46 5.56 26.94 26.94
PN40 27.5 15.01 45.08 45.08
PN63/100 42.85 41.45 74.19 70.07
CL150 4.59 1.98 29.44 29.44
CL300 25.61 14.22 45.52 45.52
CL600 34.09 34.09 - -
32 1 1/4“
JIS 10K 9.62 4.9 45.08 45.08
PN40 30.44 23.71 56.06 56.06
PN63/100 62.04 51.45 97.08 97.08
CL150 5.82 2.88 36.12 36.12
CL300 33.3 18.41 73.99 73.99
CL600 23.08 23.08 - -
40 1 1/2“
JIS 10K 12.49 6.85 56.06 56.06
Continued on next page
1) Connection flange DIN/EN 1092-1 = DN10 (3/8"), connection flange ASME = DN15 (1/2")

ABB ProcessMaster Specifications

General

Type	Electromagnetic Flowmeter
Liner Material	PTFE, PFA, Polyurethane, Rubber
Electrode Material	Stainless steel, Hastelloy, Tantalum, Titanium, Platinum
Process Connection	Flange, Wafer
Fluid Temperature	-40 to 180 °C (-40 to 356 °F) Depending on liner
Output	4-20 mA, HART, PROFIBUS PA, FOUNDATION Fieldbus
Power Supply	100 to 230 V AC, 24 V AC/DC
Protection Class	IP67
Approvals	ATEX, IECEx, FM, CSA
