Mounting
CI/FEX300/FEX500-EN FEX300, FEX500 EN - 17
Meter size DN Nominal
pressure
Max. tightening torque [Nm]
Hard/soft rubber lining PTFE, PFA, ETFE lining mm Inch PN
Steel flange Stainless steel
flange
Steel flange Stainless steel
flange
PN40 41.26 27.24 71.45 71.45
PN63 71.62 60.09 109.9 112.6
CL150 22.33 22.33 66.22 66.22
CL300 17.4 22.33 38.46 38.46
CL600 35.03 35.03 - -
50 2“
JIS 10K 17.27 10.47 71.45 71.45
PN16 14.94 8 37.02 39.1
PN40 30.88 21.11 43.03 44.62
PN63 57.89 51.5 81.66 75.72
CL150 30.96 30.96 89.93 89.93
CL300 38.38 27.04 61.21 61.21
CL600 53.91 53.91 - -
65 2 1/2“
JIS 10K 14.94 8 37.02 39.1
PN40 38.3 26.04 51.9 53.59
PN63 63.15 55.22 64.47 80.57
CL150 19.46 19.46 104.6 104.6
CL300 75.54 26.91 75.54 75.54
CL600 84.63 84.63 - -
80 3“
JIS 10K 16.26 9.65 45.07 47.16
PN16 20.7 12.22 49.68 78.19
PN40 67.77 47.12 78.24 78.19
PN63 107.4 95.79 148.5 119.2
CL150 17.41 7.82 76.2 76.2
CL300 74.9 102.6 102.6 102.6
CL600 147.1 147.1 - -
100 4“
JIS 10K 20.7 12.22 49.68 78.19
PN16 29.12 18.39 61.4 64.14
PN40 108.5 75.81 123.7 109.6
PN63 180.3 164.7 242.6 178.2
CL150 24.96 11.05 98.05 98.05
CL300 81.64 139.4 139.4 139.4
125 5“
CL600 244.1 244.1 - -
PN16 46.99 23.7 81.23 85.08
PN40 143.5 100.5 162.5 133.5
PN63 288.7 269.3 371.3 243.4
CL150 30.67 13.65 111.4 111.4
CL300 101.4 58.4 123.6 123.6
150 6“
CL600 218.4 218.4 - -
PN10 45.57 27.4 113 116.9
PN16 49.38 33.82 70.42 73
PN25 100.6 69.17 109.9 112.5
PN40 196.6 144.4 208.6 136.8
PN63 350.4 331.8 425.5 282.5
CL150 49.84 23.98 158.1 158.1
200 8“
CL300 133.9 78.35 224.3 224.3
