Mounting
18 - EN FEX300, FEX500 CI/FEX300/FEX500-EN
Meter size DN Nominal
pressure
Max. tightening torque [Nm]
Hard/soft rubber lining PTFE, PFA, ETFE lining mm Inch PN
Steel flange Stainless steel
flange
Steel flange Stainless steel
flange
PN10 23.54 27.31 86.06 89.17
PN16 88.48 61.71 99.42 103.1
PN25 137.4 117.6 166.5 133.9
PN40 359.6 275.9 279.9 241
CL150 55.18 27.31 146.1 148.3
250 10“
CL300 202.7 113.2 246.4 246.4
PN10 58.79 38.45 91.29 94.65
PN16 122.4 85.64 113.9 114.8
PN25 180.6 130.2 151.1 106.9
PN40 On request On request On request On request
CL150 90.13 50.37 203.5 198
300 12“
CL300 333.3 216.4 421.7 259.1
PN10 69.62 47.56 72.49 75.22
PN16 133.6 93.61 124.9 104.4
PN25 282.3 204.3 226.9 167.9
CL150 144.8 83.9 270.5 263
350 14“
CL300 424.1 252.7 463.9 259.4
PN10 108.2 75.61 120.1 113.9
PN16 189 137.2 191.4 153.8
PN25 399.4 366 404 246.7
CL150 177.6 100 229.3 222.8
400 16“
CL300 539.5 318.8 635.8 328.1
CL150 218.6 120.5 267.3 192.3
450 18“
CL300 553.8 327.2 660.9 300
PN10 141.6 101.4 153.9 103.5
PN16 319.7 245.4 312.1 224.8
PN25 481.9 350.5 477.1 286
CL150 212.5 116 237.3 230.4
500 20“
CL300 686.3 411.8 786.8 363.1
PN10 224.7 164.8 238.7 149.1
PN16 515.1 399.9 496.7 365.3
PN25 826.2 600.3 750.7 539.2
CL150 356.6 202.8 451.6 305.8
600 24“
CL300 1188 719 1376 587.4
PN10 267.7 204.9 On request On request
PN16 455.7 353.2 On request On request
PN25 905.9 709.2 On request On request
CL150 364.1 326.2 449.2 432.8
700 28“
CL300 1241 On request On request On request
CL150 423.8 380.9 493.3 442
750 30“
CL300 1886 On request On request On request
Continued on next page
