ABB ProcessMaster User Manual

Mounting
20 - EN FEX300, FEX500 CI/FEX300/FEX500-EN
4.2.2 Variable process connections HygienicMaster
Meter size DN Max. tightening torque
mm inch Nm
1 ... 2 1/25 ... 3/32“ PVC/POM: 0.2 Brass/1.4571: 3
3 ... 10 3/8“ 8
15 1/2“ 10
20 3/4“ 21
25 1 31
32 1 1/4“ 60
40 1 1/2“ 80
50 2 5
65 2 1/2“ 5
80 3 15
100 4 14

ABB ProcessMaster Specifications

General

Type	Electromagnetic Flowmeter
Liner Material	PTFE, PFA, Polyurethane, Rubber
Electrode Material	Stainless steel, Hastelloy, Tantalum, Titanium, Platinum
Process Connection	Flange, Wafer
Fluid Temperature	-40 to 180 °C (-40 to 356 °F) Depending on liner
Output	4-20 mA, HART, PROFIBUS PA, FOUNDATION Fieldbus
Power Supply	100 to 230 V AC, 24 V AC/DC
Protection Class	IP67
Approvals	ATEX, IECEx, FM, CSA
