ABB REF542plus - Reset Page

Table 19.-1 Menu access table (Continued)
Menu / Submenu page No
Control
Local
Control
Remote
Control
L&R
Control
Prot.
Set
Prot.
Oper.
- View Parameter Yes Yes Yes Yes Yes Yes
- Change Parameter - - - - Yes No
Control parameters
- View parameter - - - - Yes Yes
- Change parameter - - - - Yes No
Service page
- Statistics Yes Yes Yes Yes Yes Yes
- Versions Yes Yes Yes Yes Yes Yes
- Communication
address
Yes Yes Yes Yes Yes Yes
- LCD contrast Yes Yes Yes Yes Yes Yes
- MC time Yes Yes Yes Yes Yes Yes
- Load flow direction Yes Yes Yes Yes Yes Yes
- Autoreclosure mode No No No No Yes No
- IEC 60870-5-103
module
Yes Yes Yes Yes No No
Test page
- HMI Control Unit Yes Yes Yes Yes Yes Yes
- Primary No Yes No No No No
19.1. Reset page
From this page, it is possible to reset alarms and other quantities. Some reset
actions are possible only if REF542plus is in the proper mode. For example,
the fault recorder can be reset only in the set protection mode. An attempt to
reset it in the operational mode will be denied.
