ABB REM620 - LD0.MAPGAPC4 Multipurpose Analog Protection Function (4); LD0.MAPGAPC5 Multipurpose Analog Protection Function (5); LD0.MAPGAPC6 Multipurpose Analog Protection Function (6); LD0.MAPGAPC7 Multipurpose Analog Protection Function (7)

2.3.7.6 LD0.MAPGAPC4 Multipurpose analog protection function (4)
Table 77: LD0.MAPGAPC4 Multipurpose analog protection function (4)
IEC 61850 name SA name Description Values
LD0.MAPGAPC4
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
2.3.7.7 LD0.MAPGAPC5 Multipurpose analog protection function (5)
Table 78: LD0.MAPGAPC5 Multipurpose analog protection function (5)
IEC 61850 name SA name Description Values
LD0.MAPGAPC5
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
2.3.7.8 LD0.MAPGAPC6 Multipurpose analog protection function (6)
Table 79: LD0.MAPGAPC6 Multipurpose analog protection function (6)
IEC 61850 name
SA name Description Values
LD0.MAPGAPC6
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
2.3.7.9 LD0.MAPGAPC7 Multipurpose analog protection function (7)
Table 80: LD0.MAPGAPC7 Multipurpose analog protection function (7)
IEC 61850 name
SA name Description Values
LD0.MAPGAPC7
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
2.3.7.10 LD0.MAPGAPC8 Multipurpose analog protection function (8)
Table 81: LD0.MAPGAPC8 Multipurpose analog protection function (8)
IEC 61850 name
SA name Description Values
LD0.MAPGAPC8
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
1MRS757656 A Section 2
DNP3 data mappings
REM620 37
Point List Manual
