OnDelay: Used to prevent output signals to be given for spurious inputs. Normally set
to 0 or a low value. Used only for ModeOutputx: Steady.
OffDelay: Defines a minimum on time for the outputs. When used for direct tripping
of circuit breaker(s) the off delay time shall be set to approximately 0.150 seconds in
order to obtain a satisfactory minimum duration of the trip pulse to the circuit breaker
trip coils. Used only for ModeOutputx: Steady.
ModeOutputx: Defines if output signal OUTPUTx (where x=1-3) is Steady or Pulsed.
A steady signal follows the status of the input signals, with respect to OnDelay and
OffDelay. A pulsed signal will give a pulse once, when the Outputx rises from 0 to
1.
11.4 Configurable logic blocks
11.4.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
OR Function block OR - -
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Inverter function block INVERTER - -
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
PULSETIMER function block PULSETIMER - -
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Controllable gate function block GATE - -
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Exclusive OR function block XOR - -
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Logic loop delay function block LOOPDELAY - -
1MRK 505 291-UEN A Section 11
Logic
251
Application manual
