11.8.2 Application

Integer to boolean 16 conversion function (IB16A) is used to transform an integer into

a set of 16 binary (logical) signals. It can be used – for example, to connect integer

output signals from one function to binary (logical) inputs to another function. IB16A

function does not have a logical node mapping.

11.8.3 Setting guidelines

The function does not have any parameters available in the local HMI or Protection

and Control IED Manager (PCM600).

11.9 Integer to boolean 16 conversion with logic node

representation IB16FCVB

11.9.1 Identification

Function description IEC 61850

identification

IEC 60617

identification

ANSI/IEEE C37.2

device number

Integer to boolean 16 conversion with

logic node representation

IB16FCVB - -

11.9.2 Application

Integer to boolean 16 conversion with logic node representation function

(IB16FCVB) is used to transform an integer into a set of 16 binary (logical) signals.

IB16FCVB function can receive an integer from a station computer – for example,

over IEC 61850–8–1. These functions are very useful when the user wants to generate

logical commands (for selector switches or voltage controllers) by inputting an integer

number. IB16FCVB function has a logical node mapping in IEC 61850.

11.9.3 Settings

The function does not have any parameters available in the local HMI or Protection

and Control IED Manager (PCM600)

Section 11 1MRK 505 291-UEN A

Logic

256
