ABB REQ650 User Manual

IEC 61850 or
Function name
ANSI Function description Breaker
REQ650
REQ650 (A01) 3Ph/1CB/1BB REQ650 (A11) 1Ph/1CB/1BB REQ650 (B11) 1Ph/1CB/2BB
SAPTUF 81 Underfrequency function 0–2 2 2 2
SAPTOF 81 Overfrequency function 0–2 2 2 2
SAPFRC 81 Rate-of-change frequency protection 0–2 2 2 2
2.2.2 Control and monitoring functions
IEC 61850 or Function
name
ANSI Function description Breaker
REQ650
REQ650 (A01)
3Ph/1CB/1BB
REQ650 (A11)
1Ph/1CB/1BB
REQ650 (B11)
1Ph/1CB/2BB
Control
SESRSYN 25 Synchrocheck, energizing check, and
synchronizing
0–1 1 1 1
SMBRREC 79 Autorecloser for 3–phase operation 0–1 1
STBRREC 79 Autorecloser for 1/3–phase operation 0–1 1 1
SLGGIO Logic Rotating Switch for function selection
and LHMI presentation
15 15 15 15
VSGGIO Selector mini switch 20 20 20 20
DPGGIO IEC 61850 generic communication I/O
functions double point
16 16 16 16
SPC8GGIO Single point generic control 8 signals 5 5 5 5
AUTOBITS AutomationBits, command function for
DNP3.0
3 3 3 3
I103CMD Function commands for IEC60870-5-103 1 1 1 1
I103IEDCMD IED commands for IEC60870-5-103 1 1 1 1
I103USRCMD Function commands user defined for
IEC60870-5-103
4 4 4 4
I103GENCMD Function commands generic for
IEC60870-5-103
50 50 50 50
I103POSCMD IED commands with position and select for
IEC60870-5-103
50 50 50 50
SCILO 3 Logical node for interlocking
SCSWI Switch controller
QCBAY Bay control 1 1 1 1
LOCREM Handling of LR-switch positions 1 1 1 1
LOCREMCTRL LHMI control of Permitted Source To Operate
(PSTO)
1 1 1 1
Table continues on next page
Section 2 1MRK 505 291-UEN A
Application
26
Application manual
