ABB REQ650 User Manual

IEC 61850 or Function
name
ANSI Function description Breaker
REQ650
REQ650 (A01)
3Ph/1CB/1BB
REQ650 (A11)
1Ph/1CB/1BB
REQ650 (B11)
1Ph/1CB/2BB
CBC1 Circuit breaker control for 1CB 1 1 1 1
Secondary system supervision
CCSRDIF 87 Current circuit supervision 0–1 1 1 1
SDDRFUF Fuse failure supervision 0–1 1 1 1
TCSSCBR Breaker close/trip circuit monitoring 3 3 3 3
Logic
SMPPTRC 94 Tripping logic, common 3–phase output 1 1
SPTPTRC 94 Tripping logic, phase segregated output 1 1 1
TMAGGIO Trip matrix logic 12 12 12 12
OR Configurable logic blocks 283 283 283 283
INVERTER Configurable logic blocks 140 140 140 140
PULSETIMER Configurable logic blocks 40 40 40 40
GATE Configurable logic blocks 40 40 40 40
XOR Configurable logic blocks 40 40 40 40
LOOPDELAY Configurable logic blocks 40 40 40 40
TIMERSET Configurable logic blocks 40 40 40 40
AND Configurable logic blocks 280 280 280 280
SRMEMORY Configurable logic blocks 40 40 40 40
RSMEMORY Configurable logic blocks 40 40 40 40
Q/T Configurable logic blocks Q/T 0–1
ANDQT Configurable logic blocks Q/T 0–120
ORQT Configurable logic blocks Q/T 0–120
INVERTERQT Configurable logic blocks Q/T 0–120
XORQT Configurable logic blocks Q/T 0–40
SRMEMORYQT Configurable logic blocks Q/T 0–40
RSMEMORYQT Configurable logic blocks Q/T 0–40
TIMERSETQT Configurable logic blocks Q/T 0–40
PULSETIMERQT Configurable logic blocks Q/T 0–40
INVALIDQT Configurable logic blocks Q/T 0–12
INDCOMBSPQT Configurable logic blocks Q/T 0–20
INDEXTSPQT Configurable logic blocks Q/T 0–20
FXDSIGN Fixed signal function block 1 1 1 1
B16I Boolean 16 to Integer conversion 16 16 16 16
B16IFCVI Boolean 16 to Integer conversion with logic
node representation
16 16 16 16
IB16A Integer to Boolean 16 conversion 16 16 16 16
Table continues on next page
1MRK 505 291-UEN A Section 2
Application
27
Application manual
