2.3.8 Transformer bay in a solidly earthed network, connected to
double busbar switchyard
3
REQ650 (B11)
Bus 1
Bus 2
IEC10000139-1-en.vsd
IEC10000139 V1 EN
Figure 10: Transformer bay in a solidly earthed system
