ABB REQ650 User Manual

Section 12 Monitoring
12.1 IEC61850 generic communication I/O functions
SPGGIO
12.1.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
IEC 61850 generic communication I/O
functions
SPGGIO - -
12.1.2 Application
IEC 61850–8–1 generic communication I/O functions (SPGGIO) function is used to
send one single logical output to other systems or equipment in the substation. It has
one visible input, that should be connected in ACT tool.
12.1.3 Setting guidelines
The function does not have any parameters available in Local HMI or Protection and
Control IED Manager (PCM600).
12.2 IEC61850 generic communication I/O functions 16
inputs SP16GGIO
12.2.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
IEC 61850 generic communication I/O
functions 16 inputs
SP16GGIO - -
12.2.2 Application
SP16GGIO function block is used to send up to 16 logical signals to other systems or
equipment in the substation. Inputs should be connected in ACT tool.
1MRK 505 291-UEN A Section 12
Monitoring
259
Application manual
