ABB SwirlMaster FSS430 Commissioning Instructions

SwirlMaster FSS430, FSS450 VortexMaster FSV430, FSV450 | CI/FSS/FSV430/450-EN Rev. D 31
Easy Setup
Damping Qv
3.00s
Next Edit
28. Use to call up the edit mode.
29. Use / to set the damping for the volume flow.
30. Confirm the selection with .
Easy Setup
Iout at Alarm
Low Alarm
Next Edit
31. Use to call up the edit mode.
32. Use / to select the alarm current.
33. Confirm the selection with .
Easy Setup
Low Alarm
3.6000 m
A
Next Edit
34. Use to call up the edit mode.
35. Use / to set the alarm current for "Low Alarm".
36. Confirm the selection with .
Easy Setup
High Alarm
21,000 m
A
Next Edit
37. Use to call up the edit mode.
38. Use / to set the alarm current for "High Alarm".
39. Confirm the selection with .
Easy Setup
A
uto Zero
3.6000 m
A
Next OK
40. Use to start automatic balancing of the zero point for
the system.
NOTE
Prior to starting the zero point balancing, make sure that:
— There is no flow through the sensor (close all valves,
shut-off devices, etc.)
— The sensor is completely filled with the medium to be
measured
Easy Setup
Low Flow Cutof
f
0.00 %
Next Edit
41. Use to call up the edit mode.
42. Use / to set the desired value for the low flow cut-
off.
43. Confirm the selection with .
Menu
Easy Setup
Exit Select
Once all parameter have been set, the main menu appears
again. The most important parameters are now set.
44. Use to switch to the process display.
