9.3.8 Status display Lon-Bus
LED 1
Color Description Remarks
-- -- Not used
LED 2, Service LED
Color Status Description Remarks
Green flashing Application installed, but not
(yet) configured for the
network.
SYNCHROTACT 5
communications board is
runnable, but still needs to be
configured (Service key)
Green on No application installed, and
not configured for the network.
Indicates errors which were
detected by the Neuron Self-
Test Routine.
SYNCHROTACT 5
communications board is not
runnable (internal problem in
device). Try to cancel the error
as follows:
1. Switch auxiliary voltage off
and on again
2. Check whether the right
software is loaded into the
communications module
3. Check plug connection
between the
communications module
and the SYN 5010 base
board.
Otherwise the communications
module is defective.
Green off Configured and installed in a
network.
No fault!
LED 3, Error
Color Description Remarks
-- Indicates that an internal error
has occurred in the
communications module.
Try to cancel the error by
switching the auxiliary voltage
off and on.
LED 4, Wink
Color Description Remarks
-- Indicates that the node has
received a LonWorks Wink
command.
i.e. an internal diagnostic
check is currently taking place.
LED 1 LED 2
LED 3LED 4
