ABB Terra 360 CE - Mass of the EVSE (Without Packaging Material); Floor Space Requirements (Terra 360, Pre-Series)

Parameter Specification
[metric] [imperial]
Mass of a wooden crate packaged EVSE EVSE weight + 75
kg
EVSE weight + 165
lb
Maximum tipping angle 15° 15°
10.11.4 Mass of the EVSE (without packaging material)
Parameter Specification
[kg] [lbs]
Terra 360 848 1870
Terra 180 631 1391
Terra 60 480 1058
The type plate shows the specification. Refer to section 3.1.
10.11.5 Floor space requirements (Terra 360, pre-series)
X1 X2
Y1
Y2
A
A Cabinet
X1 Required width to open the rear
door
X2 Required width to open the front
door
Y1 Required depth to the rear door
Y2 Required depth to open the front
door
Parameter Specification [mm]
[mm] [in]
X1 900 35
X2 900 35
Technical data
9AKK108467A6398-EN | 002 103
